Cable Connection Fiber-glass-reinforced polyester plug head Cell Constant k 0.1 cm⁻1 Enclosure Rating IP65 Flow Rate Minimum: 100 mL/min (6 L/h) with homogeneous flow sample or 330 mL/min (20 L/h) Length 119.5 mm Measuring Principle 2-EL contacting conductivity Operating Temperature Range 125 °C maximum Pressure Range Max. 10 bar Process Connection 0.75 " NPT thread Range 0.1 - 2000 µS/cm Temperature Sensor Pt100 Class A Vessel Constant 1.00 if mounted in 8318 flow through chamber Warranty 6 months
08311=A=0000 | Z08311=A=0000
8311 2-EL电导率传感器，K=0.1 cm⁻1，D3411的备用传感器
量程：0.1 - 2000 µS/cm
8311 2-EL conductivity sensor, K=0.1 cm⁻¹, spare sensor for D3411
