Field of application
Condumax CLS19 measures conductivity in the low measuring ranges. It performs reliably and accurately in a wide range of applications. Designed for low maintenance and a long operating life, the sensor offers you best value for money.
Condumax CLS19 measures conductivity in pure and ultrapure water applications for the monitoring and control of:
Ion exchangers
Reverse osmosis
Cooling water
Distillation
Chip cleaningBenefits
Reliable and accurate measuring values at low conductivities
Best price-performance ratio
Easy installation with threaded connection
Robust design for high durability
Different cell constants provide a wide measuring rangeConductivity:
Measuring Principle Conductive Application Pure and ultrapure water Characteristic 2-electrode conductivity cell for pure water applications. Measuring range k=0,01: 0-20 µS/cm
k=0,1: 0-200 µS/cmMeasuring principle Conductive conductivity cell. Design 2-electrode conductivity cell with coaxially arranged electrodes Material Cell shaft: PES
Electrode: Stainless steel 1.4571Dimension Electrode diameter: 16 mm
(0.62 inch)Process temperature max. 60°C
max. 140°FProcess pressure max. 6 bar at 20°C
(max.87 psi at 68°F)Temperature sensor Optional with integrated Pt100 Connection Process connection: NPT 1/2"
cable:4-pole DIN-connector with Pg9Ingress protection IP65 Additional certifications Quality certification
CLS19 Analog conductivity sensor
Conductive conductivity sensor for simple standard applications in pure and ultrapure water
