Liquisys CCM253 is a standard residual chlorine measuring transmitter and can measure pH to compensate for residual chlorine measurements. With continuous rationality, measurement process and sensor detection, operational safety is improved. No matter how to choose from a large number of hardware and software modules, such as relays and bus communication, it can be fully adapted to the measurement task. It also allows the transmitter to be upgraded at any time, and its simple menu and factory calibration make configuration and operation easy and quick.

advantage

greater operational safety: continuous process check system, customized alarm settings, calibration plausibility check

Reliable chlorine and pH control: current input for flow rate monitoring and feedforward control with controller shutdown

Easy operation and service: Intuitive user interface, simple chlorine and pH calibration, manual contact control

Reduce maintenance workload: automatic cleaning function triggered by alarm and limit switch (with Chemoclean

Suitable for various applications: Multiple expansion forms, such as P(ID) controllers, timers, etc., suitable for all processes

Application areas

Liquisys CCM253 transmitter can be used with various analog total chlorine, residual chlorine, chlorine dioxide and pH sensors, suitable for the following measurement occasions:

Water & Sewage

-Sterilization process control and monitoring

-Desalination process using membrane technology

-Swimming Pool

-gas scrubber

Food & Beverage

-Disinfection of industrial process water

power plant

-cooling water disinfection

Liquisys CCM253 uses the following communication protocols and interfaces:

0/4...20 mA

HART

PROFIBUS DP

PROFIBUS PA
